Centrifugal Pump
Product Number: KW-SC-08
We're here to help:
Easy ways to get the answers you need.
- +86-029-88601839
- +86-029-88601839
- kingwell@kingwelloilfield.com
- Follow Us:
KINGWELL Centrifugal Pump Features & Benefits:
Centrifugal Pump is also called Sand Pump. With single impeller, it can offer high flow rate. It is the ideal matching equipment to provide impetus for desander, desilter and Jet mud mixer. Centrifugal pump can also be an assistant mud infusion pump and trip pump at well head.
KINGWELL Centrifugal Pump Technical Data:
Centrifugal Pump is also called Sand Pump. With single impeller, it can offer high flow rate. It is the ideal matching equipment to provide impetus for desander, desilter and Jet mud mixer. Centrifugal pump can also be an assistant mud infusion pump and trip pump at well head.
KINGWELL Centrifugal Pump Technical Data:
| Model | Flow (m3/h) | Lift(m) | Power (Kw) | Speed (RPM) | Impeller Size(Inch) | Weight(Kg) | Dimension(mm) |
| KWSB8x6A-14J | 320(1408GPm) | 35 | 75(100HP) | 1450(50Hz) | 14 | 1096 | 1968×650×1017 |
| KWSB8x6A-12J | 1750(60Hz) | 12 | |||||
| KWSB8x6A-13J | 272(1200GPM) | 35 | 55(75HP) | 1450(50Hz) | 13 | 987 | 1894×650×957 |
| KWSB8X6A-11J | 1750(60Hz) | 11 | |||||
| KWSB6x5A-13J | 200(880GPM) | 35 | 45(60HP) | 1450 (50Hz) | 13 | 786 | 1811×558×858 |
| KWSB6x5A-10J | 1750(60Hz) | 10 | |||||
| KWSB6x5A-12J | 150(660GPM) | 30 | 37(50HP) | 1450(50Hz) | 12 | 771 | 1786×558×858 |
| KWSB6x5A-9.5J | 1750(60Hz) | 9.5 | |||||
| KWSB5x4A-13J | 120(528GPM) | 35 | 30(40HP) | 1450(50Hz) | 13 | 696 | 1696×568×805 |
| KWSB5x4A-11J | 1750(60Hz) | 11 | |||||
| KWSB5x4A-12J | 90(400GPM) | 30 | 22(30HP) | 1450(50Hz) | 12 | 583 | 1649×568×800 |
| KWSB5x4A-10J | 1750(60Hz) | 10 | |||||
| KWSB4x3A-13J | 65(286GPM) | 35 | 18.5(25HP) | 1450(50Hz) | 13 | 561 | 1595×505×800 |
| KWSB4x3A-12J | 1750(60Hz) | 12 | |||||
| KWSB4x3A-12J | 55(242GPM) | 28 | 15(20HP) | 1450(50Hz) | 12 | 482 | 1550×505×755 |
| KWSB4x3A-10J | 1750(60Hz) | 10 | |||||
| KWSB4x3A-11J | 45(198GPM) | 25 | 11(15HP) | 1450(50Hz) | 11 | 464 | 1510×505×755 |
| KWSB4x3A-9.5J | 1750(60Hz) | 9.5 |
