KINGWELL Igniter and Firing Head

Xi'an KINGWELL OILFIELD MACHINERY Co., Ltd. (KINGWELL), is a highly reputable manufacturer and supplier for oilfield equipment, also a outstanding service company for complete solutions to Oil & Gas industries.

With over 10 years developing, we were developed from the beginning drilling Service Company to factory that can produce Igniter and Firing Head with good quality.

Kingwell Igniter and Firing Head has the below kinds of products:

1. Sand-proof Mechanical Firing Head
2. Dual-igniter Sand-proof Mechanical Firing Head
3. Dual-igniter Pressure Actuated Firing Head
4. Dual-Initiation Firing Head
5. Dual-Direction Pressure Actuated Firing Head
6. Tail-gun Pressure Actuated Firing Head
7. Differential Firing Head
8. Pressure-controlled Firing Head
9. Slim Hole Pressure Actuated Firing Head
10. 1.9TBG Pressure Actuated Firing Head
11. Pressure Actuated Hole Opening Compound Firing Head
12. Mechanical Full Bore Firing Head
13. Pressure Actuated Full Bore Firing Head
14. Percussion Unlocking Safety Firing Head
15. Tail Reaction Device
16. Mechanical Ignition Device
17.Pressure Ignition Device
18.Bridge Plug Charge
19.Magneto- electric Safety Detonator
20.Hp Resistance Magneto-electric Detonator HP
21.Heavy Current Safety Detonator
22.Fluid Disabled Detonator
23.Igniter
24.Dual-igniter
25.Magneto-electric Igniter
26.Bridge Plug Powder Igniter

---------------------------------

Description

Cable Head, Top Bottom Subs, Tandems Used for Perforating Gun

Description:

There are kinds of subs, Cable Head, Top Subs, Tandems, Bottom Subs and Crossovers under normal pressure and Ultra-HP

Technial Parameter:

No	Sub Type		Model	OD(mm)	OAL(mm)	Thread	O-ring size(mm)
1	Tandem	Box	68	68	165	M59×2，M53×2	52.5×3.55，46.2×3.55
2			73	74	188	M65×2，Tr65×4	57.9×3.55
			83	83	188	Tr70×4，Tr65×4	60×5.3，64.9×3.55
3			86	86	188	2 13/16-ACME，Tr65×4	57.9×3.55，64.9×3.55
4			89	89	188	3 1 /16-ACME，M80×3，Tr80×4，Tr78×4	68.6×5.7，57.9×3.55
5			102	102	127	Tr90×4，Tr65×4	78.6×5.7，57.9×3.55
6			114	114	127	Tr100×4，Tr65×4，3 15/16-ACME	90×5.3，57.9×3.55
7			127	127	127	Tr115×4，Tr65×4	103.6×5.7，57.9×3.55
8		Double Pin	51	54	150	M43×2	36.9×3.55
9			60	61	150	M53×2	46.2×3.55
10			68	68	140	M59×2，M53×2	52.5×3.55，46.2×3.55
11			73	74	167	M65×2，Tr65×4	57.9×3.55
			83	83	188	Tr70×4，Tr65×4	60×5.3，64.9×3.55
12			86	86	177	2 13/16-ACME，Tr65×4	57.9×3.55，64. 9×3.55
13			89	89	177	3 1 /16-ACME，M80×3，Tr80×4，Tr78×4，Tr65×4	68.6×5.7，57.9×3.55
14			102	102	178	Tr90×4，Tr65×4	78.6×5.7，57.9×3.55
15			114	114	178	Tr100×4，Tr65×4，3 15/16-ACME	90×5.3，57.9×3.55
16			127	127	178	Tr115×4，Tr65×4	103.6×5.7，57.9×3.55
